Temporary Barriers and Anterooms for
Healthcare
- Available in 4, 8, 10, 12 and 16 ft standard heights
- Optional SwiftWall Flex panels can be added allowing for 2.75 ft of adjustable height
- Clean install with minimal or no cutting in the field
- Beautiful frameless finished wall appearance
- All systems meet ICRA V standards
- Non-microbial, non-ferrous and non-hygroscopic
- Reusable and reconfigurable
- 5X faster install
- Sustainable
PRODUCT LINES
- Installs 5X faster
- Non-hygroscopic ABS, textured finished on both sides
- Very lightweight, durable, easy to handle
- STC21 sound rating
- ASTM E-84 Class C flame spread rated
(with optional Class A aluminum skins) - 20+ reuses
- All the benefits of SwiftWall Pro panel with up to 2.75 ft of adjustable height – no cutting required
- Superior finished wall appearance
(framework concealed within finished surface) - Available in ASTM E-84 Class A and C flame spread rating, ICRA Class V
- Installs 3X faster
- Weather resistant marine aluminum panels
- White powder coated glossy finish, mold and mildew resistant
- Extremely strong, sturdy and lightweight
- 100% reusable and recyclable
- Compatible with SwiftWall Pro
- Installs 5X faster
- Non-hygroscopic, expanded PVC skins for smooth surface on both sides
- Extremely lightweight, durable, very easy to handle
- Sound damping
- Multiple reuses
- Installs 5X faster
- Non-hygroscopic ABS, textured finished on both sides
- Very lightweight, durable, easy to handle
- STC21 sound rating
- Class C fire rated
(optional Class A aluminum skins) - 20+ reuses
- All the benefits of SwiftWall Pro panel with up to 3.5 ft of adjustable height – no cutting required
- Superior finished wall appearance
(framework concealed within finished surface) - Available in ASTM E-84 Class A and C Fire-Rating, ICRA Class IV
- Installs 3X faster
- Weather resistant marine aluminum panels
- White powder coated glossy finish, mold and mildew resistant
- Extremely strong, sturdy and lightweight
- Highly engineered for load bearing applications including wind and seismic applications
- Compatible with SwiftWall Pro
- Installs 5X faster
- Non-hygroscopic, expanded PVC skins for smooth surface on both sides
- Extremely lightweight, durable, very easy to handle
- Sound damping
- Multiple reuses
Healthcare construction or renovations require temporary barriers to meet the ASTM E-84 Class A requirement. SwiftWall’s reusable wall systems are tested and listed as meeting ASTM E-84 Class A performance for smoke and flame spread.
In most cases, as per ASHE’s NFPA 241 guidelines, a non-one-hour fire-rated temporary separation wall system is permitted when there is a working sprinkler system in place. NFPA 241 8.6.2.4 allows non-rated walls and opening protectives when a sprinkler system is installed. If the renovated area has
Healthcare construction or renovations require temporary barriers to meet the ASTM E-84 Class A requirement. SwiftWall’s reusable wall systems are tested and listed as meeting ASTM E-84 Class A performance for smoke and flame spread.
In most cases, as per ASHE’s NFPA 241 guidelines, a non-one-hour fire-rated temporary separation wall system is permitted when there is a working sprinkler system in place. NFPA 241 8.6.2.4 allows non-rated walls and opening protectives when a sprinkler system is installed. If the renovated area has a sprinkler system installed, then the separation wall can be non-rated. We recommend getting approval for this configuration from your AHJ in buildings that are not fully sprinkler protected.
Furthermore, if the sprinkler system needs to be deactivated for any reason, a fire watch protocol must be put in place until such time as the sprinkler system is working again. In these instances, SwiftWall is an excellent temporary barrier per ASHE’s NFPA 241 guidelines.
a sprinkler system installed, then the separation wall can be non-rated. We recommend getting approval for this configuration from your AHJ in buildings that are not fully sprinkler protected.
Furthermore, if the sprinkler system needs to be deactivated for any reason, a fire watch protocol must be put in place until such time as the sprinkler system is working again. In these instances, SwiftWall is an excellent temporary barrier per ASHE’s NFPA 241 guidelines.
SwiftWall Panels Meet ICRA CLASS V Standards
ICRA (Infection Control Risk Assessment) guidelines are used to prevent environment-associated infections in healthcare facilities during any construction or renovation project within patient-occupied or sensitive spaces. SwiftWall temporary wall systems provide negative air capabilities for infection control personnel and contractors that meet ICRA Class V requirements.
- Aluminum joiners adhere one panel right into the next for a virtually seamless install
- Closed-cell foam core ensures a non-hygroscopic construction
- Product versatility allows for customization to any unique space and application requirement
- Easily disinfect with common disinfectants or cleaners
SwiftWall Flex is a reusable modular panel system, but now with adjustable height to fit varying ceiling heights with no cutting and a frameless finished wall appearance. SwiftWall modular panel systems simply and quickly assemble to create and transform space – temporarily or more permanently – without the mess of drywall.
Features & Benefits
- Adjustable height – no cutting required
- Up to 2.75 ft of adjustment on all standard height panels (4, 8, 10, 12, 16 ft by 4 ft wide)
- Highest value offering in the adjustable barrier market
- Superior finished wall appearance – framework concealed within finished surface
- Available in ASTM E-84 Class A and C flame spread rating, ICRA Class V
- 4 ft wide panels
- Sliding, adjustable height top panel – use the provided Allen wrench to loosen panels, slide top panel to required height and re-tighten to secure in place
- Manufactured with non-hygroscopic materials that do not absorb or retain moisture
- Installs 5x faster than studs and drywall
- Highly durable – stronger than drywall
